Sewage Treatment Plant
Packaged, pre-fabricated sewage treatment systems engineered for domestic and industrial effluent — compact, low-noise, and built for sites where space and time are both constrained.
What Sewage Treatment Involves
Sewage treatment is the process of removing contaminants from sewage water (runoff effluents and domestic effluents). It includes physical, chemical, and biological processes to remove physical, chemical and biological contaminants. Its objective is to produce environmentally-safe treated water and a treated solid waste suitable for disposal or reuse as manure.
Sewage treatment is designed using the following methods
- Extended Aeration with Activated Sludge Process
- Membrane Bio-Reactor (MBR) Technology
- Fluidized Bed Bio-Reactor Process (FBBR)
- Submerged Aerobic Fixed Film Process (SAFF)
Sewage Treatment Generally Involves Three Stages
Primary Treatment
Screening and sedimentation to remove solids and suspended matter from raw sewage.
Secondary Treatment
Biological degradation of dissolved and suspended organic matter using activated micro-organisms.
Tertiary Treatment
Final polishing of treated water to meet discharge, reuse or irrigation standards.
Packaged Systems, Engineered to Fit the Site
Blueoasis Technologies offers a wide range of pre engineering, pre fabricated packaged sewage treatment systems to handle domestic and industrial sewage originating from industrial residences, large commercial complexes, small and medium industries using suitable treatment methods matching the clients requirement.
Standard modules facilitate a shorter delivery period. The completely pre engineered units require very less civil works and can be erected and commissioned in a short time span. The pre fabricated units are independent of site location (i.e.) in places where there is space constraint or cost of space is very high, these units can be located either on the top of the building, structures or in the basement.
The packaged units work on a media based biological degradation. The specifically developed media made from UV stabilized and chemically resistant propylene offers an ideal condition for growth of micro organisms to degrade the incoming organic contaminants. The use of media also reduces the aeration tank sizes substantially thereby reducing the footprint of Sewage Treatment plant. The process air required is provided by means of twin a lobe type air blower which transfers air through rugged EPDM diffusers. The media also substantially reduces the sludge generation from these units.
Options are available to house the blower in sound proof enclosures to reduce noise thus facilitating the location of units close by to residential units. Packaged units come in standard modules with capacities ranging from 5 m³/day to 200 m³/day.
Modular Capacity Range
Standard packaged modules span 5 m³/day to 200 m³/day, sized to match residential, commercial and light-industrial demand without over-building.
Pre-Fabricated · Space-Flexible · Low NoiseShorter Delivery Period
Pre-engineered, pre-fabricated modules need minimal civil work and can be erected and commissioned quickly.
Site-Flexible Installation
Units can be located on rooftops, structures or basements — suited to sites with space or cost constraints.
Media-Based Biological Treatment
UV-stabilized, chemically resistant media reduces aeration tank size, footprint and sludge generation.
Low-Noise Operation
Sound-proof blower enclosures are available, allowing units to sit close to residential areas.
